Ceramic Anti-Static Floor: The Ultimate Solution for Static Control and Durability
The Ceramic Anti-Static Floor is a high-performance flooring solution designed to provide superior electrostatic discharge (ESD) protection in environments that require strict static control, such as data centers, electronics manufacturing, laboratories, and clean rooms. Made from durable ceramic materials, this floor combines excellent static dissipation, high durability, and easy maintenance, offering long-term protection for sensitive electronic equipment.
This article will cover the material specifications, after-sales service, installation guidelines, and certification standards of the Ceramic Anti-Static Floor, providing detailed insights into its features, benefits, and why it’s the preferred choice for high-tech and industrial environments.
The Ceramic Anti-Static Floor is made from advanced ceramic materials that are engineered to offer both high compression resistance and superior electrostatic protection.
The floor tiles are made from high-quality ceramics that are infused with conductive materials to enable static dissipation. These materials are specifically chosen to ensure that the floor remains durable, resistant to wear and tear, and provides effective ESD protection in critical environments.
Main Components: The floor consists of ceramic tiles with a conductive layer applied to the surface, which facilitates the safe neutralization of static charges.
Coating: A conductive anti-static coating is applied on the surface, ensuring long-lasting ESD protection.
| Property | Specification |
|---|---|
| Material | High-quality ceramic with conductive coating |
| Surface Resistance | < 1 x 10^6 ohms (optimum ESD protection) |
| Thickness | 10mm to 15mm depending on application |
| Size | Customizable sizes (e.g., 600mm x 600mm, 600mm x 1200mm) |
| Weight | Approx. 4-5 kg per tile |
| Compression Resistance | High load-bearing capacity, suitable for heavy equipment |
| Chemical Resistance | Resistant to mild chemicals, oils, and solvents |
| Fire Resistance | Conforms to international fire safety standards |
| Durability | Long-lasting, resistant to wear and tear |
High ESD Protection: The conductive ceramic surface ensures that any static charge is quickly dissipated, preventing damage to sensitive electronics.
Compression Resistance: Ceramic floors are highly resistant to compression, making them ideal for environments with heavy machinery or high foot traffic.
Durability: The ceramic tiles are scratch-resistant and can withstand frequent cleaning without losing their effectiveness.
We believe in providing comprehensive after-sales support to ensure your Ceramic Anti-Static Floor continues to perform at its best.
We offer a 10-year warranty on all Ceramic Anti-Static Floors. This warranty covers defects in materials and workmanship under normal conditions.
| Warranty Coverage | Details |
|---|---|
| Duration | 10 years from the date of installation |
| Includes | Manufacturing defects, material failure, and structural issues |
| Excludes | Damage due to misuse, improper installation, or harsh chemicals |
| Claim Process | Contact customer support for an inspection and repair service |
Our technical support team is available to assist with installation, troubleshooting, and maintenance queries.
Online Support: Contact us through email or our website for non-urgent inquiries and advice.
Phone Support: Our technical team is available for phone support during business hours.
On-Site Support: For complex installation issues or maintenance requirements, we offer on-site support at your location.
Regular cleaning and periodic inspections are essential for maintaining the effectiveness of the Ceramic Anti-Static Floor.
Cleaning: Use a soft mop with a neutral detergent to clean the floor. Avoid using abrasive cleaning agents, which could damage the ceramic surface.
Inspection: Conduct regular inspections every 6-12 months to check for any surface damage or wear. If any cracks or chips are found, these should be repaired immediately to maintain effective ESD protection.
Proper installation is crucial to ensure the floor functions as intended. Here’s a step-by-step guide to installing the Ceramic Anti-Static Floor.
Surface Preparation: Ensure that the subfloor is clean, dry, and level. Any unevenness in the base can affect the installation and performance of the floor.
Temperature and Humidity: The installation should be done at temperatures between 18°C and 25°C (64°F to 77°F), with humidity levels between 30% and 60% for optimal results.
Step 1: Apply a conductive adhesive to the subfloor, ensuring it is spread evenly.
Step 2: Place the Ceramic Anti-Static Floor tiles on the adhesive, starting from one corner of the room. Press each tile firmly into place.
Step 3: After laying the tiles, use a rubber roller to ensure they adhere securely to the adhesive and eliminate any air pockets.
Step 4: Allow the adhesive to set for 24 hours before walking on the floor.
Step 5: Connect the grounding system to ensure proper static dissipation. Follow the manufacturer’s instructions for grounding installation.
Curing Time: After installation, the floor should be left undisturbed for at least 24-48 hours to allow the adhesive to fully cure.
Grounding: Grounding the floor is essential for effective ESD protection. This process should be done as part of the final installation procedure.
The Ceramic Anti-Static Floor adheres to several internationally recognized certification standards, ensuring its quality, safety, and performance.
Our floor meets IEC 61340-5-1 standards for electrostatic control, ensuring that the ceramic floor provides effective protection against electrostatic discharge in sensitive environments.
The Ceramic Anti-Static Floor complies with ISO 9239-1 and EN 13501-1 fire safety standards, ensuring that the floor does not contribute to the spread of fire in critical facilities.
Our ceramic tiles have been tested for chemical resistance and comply with industry standards for exposure to common cleaning agents, oils, and mild solvents, making them suitable for environments with a variety of chemicals.
We adhere to ISO 14001 environmental management standards during the manufacturing process, ensuring minimal environmental impact and a sustainable product lifecycle.
The Ceramic Anti-Static Floor offers a comprehensive solution for environments where electrostatic discharge (ESD) protection and durability are critical. Its high-quality ceramic composition, superior ESD protection, and long-lasting performance make it an ideal choice for industries such as electronics manufacturing, data centers, and clean rooms. With easy installation, low maintenance, and comprehensive after-sales service, this floor ensures the safety of sensitive equipment while maintaining aesthetic appeal and operational efficiency.
For more information or to request a customized quote, please contact us today. Our team is ready to assist you with all your flooring needs.
